Large Format Bagging Machines


This machine is made in CHINA



A large size highly versatile automatic vertical form fill seal sachet packaging machine (FFS machine) suitable for packing almost any product for food service, toys, hardware, pharmaceutical, contract packing and other industries.

This highly versatile fully run automatic machine can thus be used for variety of products like snack foods, potato chips, grain, oatmeal, coffee, sugar, monosodium glutamate, salt, the seasoning powder, pepper, health tea, hardware parts etc.

The FFS-2000 is controlled by a double SCM (single chip) system and with a large LCD. There is a clear man-machine interface that can be easily understood coupled with a DELTA VVVF drive we get a sophisticated large format packing machine with advanced features.

Provisions are made in the machine for intelligent protection to maximize the yield and reduce wastage while maintaining machine stability. The machine will automatically stop functioning and display the failure information in the event of temperature control failure, heater burn-out failure, photo-electric failure or even when the machine runs out of film.

All these advanced features make the machine very stable and easy to use, thus resulting in high yield and low wastage at a very attractive cost.


OUTSTANDING FEATURES

#    Full epoxy coated rust resistant body.

#    Single power train. No need for compressed air.

#    All contact parts like the forming tube, conveyor buckets, product hopper (reservoir), volumetric filler and measuring cups executed in aisi 304 stainless steel.

#    Hot foil printing unit for imprinting expiry date, batch number on each individual pouch.

#     Option for nitrogen flushing of each individual pouch, for high sanitization.

#     Delta Variable Speed (VVVF) drive

#     Settings for temperature, length, counter, photo-electric unit, heating, as well as machine commands like Mix, Move, and run or Stop operated by light press keys.

#     Microcomputer (SCM) Controller with a 115 mm x 64 mm LCD ENGLISH Display with a simple and easy to understand Man-Machine Interface

#     Spares available on demand at reasonable prices. Technical support available around the year, around the clock!

#     Accurate filling and easy weight adjustment with a high precision volumetric cup filler. Also available an optional MULTI HEAD WEIGHER.

#     Runs on a regular 220V AC single phase power supply. Can be ordered with an optional step up transformer for countries with 110V AC power supply.

#     Machine LCD will show the error message for all problems encountered during operation for easy identification by the operator.

#     Electrical & mechanical protections available for compliance with accepted safety standards.

CLICK HERE To get a quotation from us as per YOUR specific requirement!

TECHNICAL SPECIFICATION

Sealing Type .... Pillow pack / Centre Seal / Back Fin seal

Volumetric Capacity per sachet .... 500-1700 ml

Bag size .... 100 mm - 200 mm (width) x 150 mm - 300 mm (length)

Machine Speed** .... 20 - 40 bags per minute

Packing Material .... Heat Sealable laminated film like PET + PE, Foil + PE, Paper + Foil + PE, PET + Foil + PE, Paper + PE, and Heat Sealable Tea Bag Paper

Electricals .... Power Supply: AC 220V 50Hz/60Hz Single Phase

Machine Dimensions(packed) .... L x W x H :
Main Body: 1640 x 1740 x 2050 (mm)
Conveyor System: 480 x 3087 x 2050 (mm)
Filling System: 830 x 1130 x 1460 (mm)
Other Parts: 950 x 1230 x 170 (mm)

Machine Weight (Packed) .... 500 Kgs

**The packing speed of the machine depends upon the flow properties of the product and the choice of packaging material used.
